| 移動式
SF型 |
| 馬力: |
1 HP ~ 3 HP |
| 風量: |
16 M3/min ~ 32 M3/min |
| 專利號碼: |
85313 |
|
|
|
|
TYPE: |
MOTOR |
SUCTION |
CAPACITY |
SIZE(MM) |
| SF-1 |
1 HP*2P |
4"*2孔holes |
18M3/min |
610 Ø*1800H |
| SF-2 |
2 HP*2P |
4"*3孔holes |
26M3/min |
750 Ø*1900H |
| SF-3 |
3 HP*2P |
5"*2孔holes |
32M3/min |
810 Ø*2300H |
|
| 固定式
FX
型 |
| 馬力: |
1 HP ~ 10 HP |
| 風量: |
16 M3/min ~ 85 M3/min |
| 專利號碼: |
85313 |
|
|
|
|
TYPE: |
MOTOR |
SUCTION |
CAPACITY |
SIZE(MM) |
| FX-2 |
2 HP*2P |
150 Ø |
27M3/min |
800*800*2400H |
| FX-3 |
3HP*2P |
180 Ø |
34M3/min |
800*800*2700H |
| FX-5 |
5 HP*2P |
230 Ø |
50M3/min |
950*950*2900H |
| FX-75 |
75HP*2P |
250 Ø |
70M3/min |
1100*1100*3000H |
|
